Availability: In stock
Free standard shipping available
groov RIO EMU
Monitor 3-phase power data with edge intelligence and real-time analytics.
$995.00 ex. GST
The groov RIO EMU (GRV-R7-I1VAPM-3) is an intelligent, edge-ready power and energy monitoring unit that delivers real-time visibility into electrical usage. Ideal for industrial, commercial, and facility energy management, it combines high-accuracy voltage and current sensing with built-in data processing, storage, and protocol conversion—all in a compact, standalone module.
Specifications
- Model: GRV-R7-I1VAPM-3
- Measurement Type: AC voltage, current, power, energy
- Voltage Inputs:
- 3-phase delta or wye
- 80–277 VAC line-to-neutral
- 80–480 VAC line-to-line
- Current Inputs:
- 3 channels
- Supports 0–1 A or 0–5 A CTs (selectable per channel)
- 24-bit resolution
- Accuracy:
- Voltage: ±0.1%
- Current: ±0.2%
- Power: ±0.5%
- Sample Rate: 64 samples per cycle (50/60 Hz)
- Power Input: 10–32 VDC
- Power Consumption: ~5 W typical
- Embedded Tools:
- Node-RED
- groov Manage
- Built-in web-based HMI (groov View)
- Secure Shell (SSH) access
- Supported Protocols:
- MQTT with Sparkplug B
- OPC UA
- Modbus TCP/RTU
- REST API
- SNMP
- Network Interfaces:
- Dual Gigabit Ethernet ports (switchable)
- VLAN support
- Data Storage: 4 GB internal storage
- Operating Temperature: -20 to 70 °C
- Dimensions (HxWxD): 104.6 mm x 36 mm x 124 mm
- Weight: ~0.36 kg
- Certifications: UL/cUL, CE, ATEX, UKCA
- Build: Made in the USA, lifetime guarantee
- Use With: Standard CTs (0–1 A or 0–5 A), groov RIO accessories, DIN rail mount
