GRV-IMA-24
Analog current input module, 24 channels, 0–20 mA, 4–20 mA, ±20 mA
$0.00 ex. GST
The GRV-IMA-24 provides 24 digital input channels for detecting 0–250 VAC/VDC signals. Channels are non-isolated but group-isolated, and support both AC and DC inputs. Includes status LEDs and touchpad diagnostics. UL and ATEX approved, -20 to 70 °C rated, made in the USA, and guaranteed for life.
Specifications
- Channels: 24 digital inputs (non-isolated, group-isolated)
- Input Voltage Range: 0–250 VAC/VDC
- Input Threshold:
- ON: ≥90 VAC/VDC
- OFF: ≤30 VAC/VDC
- Channel-to-Logic Isolation: 3,000 V (module-level)
- Indicators:
- LED on module cover (status)
- LED per channel (input state)
- Touchpad: Triggers module info display on groov EPIC processor
- Operating Temperature: -20 to 70 °C
- Certifications: UL Hazardous Locations, ATEX compliant
- Build: Made in the USA, Guaranteed for life
- Compatibility: For use with groov EPIC processors (GRV-EPIC-PR1, PR2)
